Panic Bar
UACC-PanicBar
A single-latched bar installed on emergency exit doors, allowing quick and easy egress by pushing the bar to open the door during emergencies.SpecificationsMechanical Dimensions 838 x 294 x 94 mm...
Or build it into a bundle — save up to 15% ↓What it is, and who it is for.
What it needs to run
PoE power and a UniFi Network host. If you have neither, both are in the bundle builder below.
A single-latched bar installed on emergency exit doors, allowing quick and easy egress by pushing the bar to open the door during emergencies.
Specifications
Mechanical
| Dimensions | 838 x 294 x 94 mm (33 x 11.6 x 3.7") |
| Weight | 5.8 kg (12.8 lb) |
| Enclosure Material | Aluminum, stainless steel |
| Supported Door Width | 3′ standard for door width of 2′4″ to 3′ (711 to 914 mm) |
| Supported Door Thickness | 1-3/4” (44 mm) and 2” (51 mm) thick of metal or wood door |
| Strike | For 3/4” (19 mm) stop |
| Reversible | Non-handed, reversible for all functions and trims |
| Stiley | 4-1/4” (108 mm) minimum |
| Connection | 2 lines for dry relay |
| Wiring Connection | Dry output Contact rating: 30V DC, 1A Push = Short/Release = Open Bar Position Sensor |
Hardware
| Certifications | UL 305, UL 10C, CAN/ULC-S132 ANSI/BHMA A156.3 Grade 1 Exit Devices Meets California Building Code Sec. 11B-309.4. |
