Access Point AC Pro
UAP-AC-PRO-US · Single Unit
Ceiling-mounted WiFi 5 AP with 6 spatial streams designed for large offices.Note. PoE power adapter included with single unit purchases.Key features WiFi 5 6 spatial streams 140 m² (1,500 ft²)...
Or build it into a bundle — save up to 15% ↓What it is, and who it is for.
What it needs to run
PoE power and a UniFi Network host. If you have neither, both are in the bundle builder below.
Ceiling-mounted WiFi 5 AP with 6 spatial streams designed for large offices.
Note. PoE power adapter included with single unit purchases.
Key features
WiFi 5
6 spatial streams
140 m² (1,500 ft²) coverage
250+ connected devices
Powered using PoE*
GbE uplink
*PoE power adapter included with single unit purchases.
Specifications
Overview
| Dimensions | ⌀196.7 x 35 mm (⌀7.7 x 1.4") |
| WiFi Standard | WiFi 5 |
| Spatial Streams | 6 |
| Coverage Area | 140 m² (1,500 ft²) |
| Max. Client Count | 250+ |
| Uplink | GbE |
| Mounting | Ceiling, Wall (Pro Mount Supported) |
| Power Method | PoE Supports passive 48V |
Performance
| 5 GHz | 3 x 3 (DL MU-MIMO) |
| 2.4 GHz | 3 x 3 (DL MU-MIMO) |
| 5 GHz | 1.3 Gbps (BW80) |
| 2.4 GHz | 450 Mbps (BW40) |
| 5 GHz | 3 dBi |
| 2.4 GHz | 3 dBi |
| 5 GHz | 22 dBm |
| 2.4 GHz | 22 dBm |
| Max. BSSIDs | 8 per Radio |
| 802.11ac (WiFi 5) | 6.5 Mbps to 1.3 Gbps (MCS0 - MCS9 NSS1/2/3, VHT 20/40/80) |
| 802.11n | 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40) |
Hardware
| Max. Power Consumption | 9W |
| Supported Voltage Range | 44–57V DC |
| Networking Interface | (2) GbE RJ45 ports |
| Weight | Device: 350 g (12.4 oz) With mount: 450 g (15.9 oz) |
| Management | Ethernet |
| Enclosure Material | Polycarbonate |
| System | Status |
| Channel Bandwidth | HT 20/40, VHT 20/40/80 (MHz) |
| Certifications | CE, FCC, IC, Anatel: 01943-16-08356 |
| Operating Frequency | US/CA: 2400 - 2472 MHz U-NII-1: 5150 - 5250 MHz U-NII-2A: 5250 - 5350 MHz U-NII-2C: 5470 - 5725 MHz U-NII-3: 5725 - 5850 MHz Worldwide: 2400 - 2483.5 MHz 5150 - 5850 MHz For worldwide, it depends on the regulatory region |
| Ambient Operating Temperature | -10 to 70° C (14 to 158° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
Downloads & documents
Build around the Access Point AC Pro.
It's already in your kit below. Add a gateway and PoE and the discount starts working. Discount tiers climb with the bundle — the bars fill as you build.
Type your address. We'll spec the building.
Square footage, floors, rooms, construction type — turned into an AP count, a switch size, and a gateway that fits. No guesswork, no overbuying.
Four quick questions size the kit. Property-records autofill is in the build phase.
Enter an address and the plan appears here —
property facts first, then the kit.
Pick the right one, not the biggest one
The honest line-up from wifi & access points. Most buyers reading this page should buy the middle column.
