UniFi Device Bridge
UDB-US
Plug-and-play, wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link.Note. UniFi Consoles and APs must have the latest software updates installed.Key features (1) GbE LAN port that provides up to...
Or build it into a bundle — save up to 15% ↓What it is, and who it is for.
What it needs to run
PoE power and a UniFi Network host. If you have neither, both are in the bundle builder below.
Plug-and-play, wireless bridging PoE adapter with integrated UniFi WiFi Auto-Link.
Note. UniFi Consoles and APs must have the latest software updates installed.
Key features
(1) GbE LAN port that provides up to 15W of PoE
5 GHz band with up to 867 Mbps throughput rate
Compatible with UniFi Protect PoE cameras, Talk phones, and various IoT devices via an Ethernet connection
Note. UniFi Consoles and APs must have the latest software updates installed.
Specifications
Overview
| Dimensions | 130 x 55 x 34 mm (5.1 x 2.2 x 1.3") |
| WiFi Standard | WiFi 5 |
| Spatial Streams | 2 |
| Mounting Locations | Wall, table |
| Mounting | Wall (Included) |
| Power Method | 100–240V AC, 0.45A Max., 50/60 Hz |
Performance
| 5 GHz | 2 x 2 |
| 5 GHz | 866.7 Mbps (BW80) |
| 5 GHz | Internal: 5 dBi External omni: 4 dBi, 360° x 30° |
| 5 GHz | 21 dBm |
| 802.11ac (WiFi 5) | 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80) |
| 802.11n | 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
| 802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Wireless Security | WPA2 AES |
Hardware
| Max. Power Consumption | 25W (AC input) 10W (Excluding PoE output) |
| Supported Voltage Range | 100–240V AC |
| Networking Interface | (1) GbE RJ45 port |
| Antennas | (1) Internal antenna (1) RP-SMA connector for external omni-antenna |
| Management | WiFi |
| Channel Bandwidth | 20/40/80 (MHz) |
| Weight | 200 g (7.1 oz) |
| Enclosure Material | Polycarbonate |
| Mount Material | Polycarbonate |
| Button | (1) Factory reset |
| System | (4) Blue: signal (1) White/blue: indicator |
| Certifications | CE, FCC, IC, Anatel: 03885-25-08356 |
| Operating Frequency | US/CA: U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz Worldwide: 5150 - 5875 MHz For worldwide, it depends on the regulatory region |
| Ambient Operating Temperature | -10 to 40° C (14 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
