Enterprise Fortress Gateway
EFG
25G Cloud Gateway with 500+ UniFi device / 5,000+ client support, 12.5 Gbps IPS routing, and complete high availability.Note. Shadow Mode High Availability with automatic failover (VRRP) requires UniFi OS...
Or build it into a bundle — save up to 15% ↓What it is, and who it is for.
What it needs to run
PoE power and a UniFi Network host. If you have neither, both are in the bundle builder below.
25G Cloud Gateway with 500+ UniFi device / 5,000+ client support, 12.5 Gbps IPS routing, and complete high availability.
Note. Shadow Mode High Availability with automatic failover (VRRP) requires UniFi OS 4.0 and later. Must be paired with another EFG.
90 days of Professional Phone Support is included for purchases made through the UI Store in the US, Canada, Europe, and the UK.
Specifications
Overview
| Dimensions | 442.4 x 43.7 x 325 mm (17.4 x 1.7 x 12.8") |
| Managed UniFi Devices | 500+ |
| Simultaneous Users Connected | 5,000+ Performance may be degraded with advanced gateway features (e.g., Traffic Identification) |
| Max. WAN Port Count | 5 |
| Default WAN Ports | (1) 25G SFP28 (1) 2.5 GbE RJ45 |
| 2.5 GbE RJ45 | 2 (2.5G/1G/100M/10M) |
| 10G SFP+ | 2 (10G/1G) |
| 25G SFP28 | 2 (25G/10G/1G) |
| IDS/IPS Throughput | 12.5 Gbps |
| SSL/TLS Inspection Concurrent Sessions | 10,000 |
| Concurrent Sessions | 1 Million |
| New Sessions / Second | 71,000 |
| Form Factor | Rack mount (1U) |
| Redundancy | Shadow Mode (VRRP) Gateway Failover (2) Hot-Swappable PSUs |
Security
| IDS/IPS Signatures | 95,000+ with CyberSecure Enterprise |
VPN & SD-WAN
| Identity Endpoint One-Click VPN | 1.2 Gbps |
| Teleport | 1.2 Gbps |
| WireGuard | 1.2 Gbps |
| OpenVPN | 210 Mbps |
| L2TP | 280 Mbps |
| Site Magic | 1.1 Gbps |
| OpenVPN | 120 Mbps |
| IPsec | 580 Mbps |
| WireGuard | 980 Mbps |
| OpenVPN | 180 Mbps |
Hardware
| Max. Power Consumption | 82W |
| Power Method | Universal AC input, 100–240V AC, 7A Max., 50/60 Hz |
| Power Supply | (2) Hot-swappable 150W CRPS |
| Supported Voltage Range | 100–240V AC |
| Heat Dissipation | 280 BTU/hr |
| Processor | 18-core ARM® v8.2 at 2 GHz |
| Weight | 6.5 kg (14.3 lb) |
| Enclosure Material | Aluminium CNC, SGCC steel |
| LCM Display | 1.3" touchscreen |
| Management | Ethernet Bluetooth |
| Button | (1) Factory reset |
| ESD/EMP Protection | Air: ± 8kV, contact: ± 4kV |
| Ambient Operating Temperature | 0 to 40° C (32 to 104° F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC, Anatel: 06375-24-08356, SRRC |
Software
| Mobile App | UniFi iOS™:Version 10.16.2 and later UniFi Android™: Version 10.17.2 and later |
